Test Clip With 1 Board+CH341A Programmer Module USB Motherboard Routing Liquid Crystals Disassembly Free SOP8 Test Tool

Product features:.

1 / 5 · Enlarge
Test Clip With 1 Board+CH341A Programmer Module USB Motherboard Routing Liquid Crystals Disassembly Free SOP8 Test Tool
1 / 5

₹1,912

Price including GST

Available to order

Quantity

1

Dispatch within 1–2 business days. Delivery is expected 3–7 business days after dispatch. Review your order details in the cart.

Delivery

Free on orders above ₹999. Dispatch within 1–2 business days. Delivery is expected 3–7 business days after dispatch.

Returns & warranty

Return eligibilityWarranty policy

About this product

Product features:

  1. Support 3 power supply modes: 5V external power supply,
  2. 3V external power supply, external power supply (requires
  3. 3V-5V). With 3 LEDs: TXD LED, RXD LED, POWER LED. GND, RXD, TXD, 3V3, 5V: using a curved pin pin out. The rest of the function PIN: reserved pads CTS, RTS. Instructions for use: (to access the MCU as an example). GND: connected to GND. RXD: connect to MCU.TX (Signal flow: MCU.TX - FT232 - PC.RX). TXD: connect to MCU.RX (signal flow: PC.TX - FT232 - MCU.RX). 3V3/5V: output

Size & weight

Weight
65 g
Dimensions
10 cm × 5 cm × 2 cm
